Electronic Force Gauge - MM-601A

  • Simple and accurate handheld force measurement
  • Hold and zero functions
  • One touch tare setting
  • Rechargeable batteries or AC
  • External I/O for analog out and measurement hold
  • Easy-view LCD
  • Analog force output

MM-601A is a portable electronic force gauge for setting and verifying force for resistance spot welders.

Specifications

Power Supply Rechargeable battery and AC charger
Current Sensor Torodial coil (see table in brochure)
Current Range 1.00 - 9.99A, 5.0 - 49.9kA
Time Range 1 - 99 cycles or 0.01 - 0.80 sec.
Conduction Angle 30° - 180°
Dimensions W x D x H In (mm) 2.95 x 1.18 x 6.7 (75 x 30 x 170)
Weight Lbs. (Kg) 1.1 (0.5)
